Technical Specs
| TYPE CODE | RATED CAPACITY ( kgs.) | RAISED HEIGHT ( mm ) | WORKING HEIGHT ( mm ) | PLATFORM SIZE ( mm ) | OUTSPREAD SIZE ( mm ) | POWER SOURCE AC / DC | BATTERY CHARGER | LIFTING MOTOR AC / DC | OVERALL DIMENSION LxW x H (mm) | WEIGHT AC / DC (approx.) |
|---|---|---|---|---|---|---|---|---|---|---|
| VXAWP-DM 300 / 8000 | 300 | 6000 | 8000 | 1450 X 600 | 2450 X 2450 | 220-240 V / 12 V | 2x6v /200Ah 12 V | 220v / 1.5kw 12 V / 2.5 kw | 1800x870x1870 | 500 kgs. 540 kgs. |
| VXAWP-DM 300 / 10000 | 300 | 8000 | 10000 | 1450 X 600 | 2450 X 2450 | 220-240 V / 12 V | 2x6v / 200Ah 12 V | 220v / 1.5kw 12 V / 2.5 kw | 1800x870x1870 | 570 kgs. 610 kgs. |
| VXAWP-DM 250 / 12000 | 250 | 10000 | 12000 | 1450 X 600 | 2450 X 2450 | 220-240 V / 12 V | 2x6v / 200Ah 12 V | 220v / 1.5kw 12 V / 2.5 kw | 1800x870x1870 | 728 kgs. 768 kgs. |
| VXAWP-DM 200 / 14000 | 200 | 12000 | 14000 | 1450 X 600 | 2450 X 2450 | 220-240 V / 12 V | 2x6v / 200Ah 12 V | 220v / 1.5kw 12 V / 2.5 kw | 1800x870x2150 | 825 kgs. 865 kgs. |
| VXAWP-DM 200 / 16000 | 200 | 14000 | 16000 | 1450 X 600 | 2450 X 2450 | 220-240 V / 12 V | 2x6v / 200Ah 12 V | 220v / 1.5kw 12 V / 2.5 kw | 1800x870x2400 | 870 kgs. 910 kgs. |
